SPS Brand APCRBC2F-PHR High Rate Rechargeable Battery Cartridge High-Capacity ReplacementAPC RBC2 (SGRBC2F-PHR) UPS Models

SPS Brand APCRBC2F-PHR High Rate Rechargeable Battery Cartridge High-Capacity ReplacementAPC RBC2 (SGRBC2F-PHR) UPS Models

(No reviews yet) Write a Review

SKU:
SGRBC2F-PHR_1_AL000
UPC:
681827855204
Condition:
New
Availability:
Usually Ships in 24 hours
Weight:
5.00 LBS
Shipping:
Free Shipping
Volt:
12 V
Capacity:
9 Ah
LENGTH:
5.94 IN
WIDTH:
2.96 IN
HEIGHT:
3.96 IN
Weight:
5 LBS PER UNIT
TERMINAL:
T2/F2 Faston Tab (.250 inch)
MSRP: $88.00
$44.00
(You save $44.00 )
Front view of the battery showing terminal connections and product labelingAPC RBC2F-PHR replacement battery. Compatible with SmartUPS VS420 units UPS models. 12V 7Ah battery with T2 terminals.

SPS Brand APCRBC2F-PHR High Rate Rechargeable Battery Cartridge Compatible with APCRBC2 UPS Models

Key Features

  • High Rate Performance: Features a 12V 9Ah high rate sealed lead acid battery, engineered for UPS applications to support higher loads for shorter periods and deliver superior runtime at a given load.
  • Plug & Play Installation: Shipped fully assembled, charged, and ready to install—no assembly required. Simply swap out your old cartridge for immediate power restoration.
  • F2/T2 Terminal (.250”): Equipped with industry-standard F2/T2 (.250 inch) faston tab terminals for secure and easy UPS connections.
  • Wide Compatibility: Directly replaces APC RBC2 and fits a broad range of APC UPS models, including Back-UPS and Smart-UPS series (see compatibility list below).
  • Built for Reliability: Manufactured with high-quality, ISO-certified batteries for dependable performance and a design life of 3–5 years at 77°F (25°C).
  • 1-Year Full Warranty: Backed by a 1-year warranty.
  • Dimensions & Weight: Compact size (5.94 x 2.96 x 3.96 inches); weight: 5 lbs for easy handling and installation.

Product Description

The SPS Brand APCRBC2FI-PHR High Rate Rechargeable Battery Cartridge is a premium, plug-and-play replacement for the APC RBC2, designed to deliver enhanced performance and extended runtime for your UPS system. Built with a high rate 12V 9Ah sealed lead acid battery, this cartridge is ideal for demanding environments where higher load support and reliable backup power are essential.

Arriving fully assembled and charged, the APCRBC2FI-PHR is easy to install and compatible with a wide range of APC UPS models, including Back-UPS 200/250B/280/300/400/500M, Back-UPS CS500, Back-UPS Pro 280/420/500CLR, Smart-UPS 420, and more. Manufactured in ISO-certified facilities, it offers a design life of 3–5 years and is backed by a 1-year full warranty. Sigma Batteries also provides a free recycling program for spent cartridges.

Technical Specifications

Specification APCRBC2FI-PHR Details
Battery Type High Rate Sealed Lead Acid
Voltage 12V
Capacity 9Ah
Terminal Type F2/T2 Faston Tab (.250 inch)
Dimensions (LxWxH) 5.94 x 2.96 x 3.96 inches
Weight 5.5 lbs
Operating Temp. 32°F to 104°F (0°C to 40°C)
Expected Life 3–5 years at 77°F
Warranty 1 Year
Plug & Play Yes

Comparison Table: APCRBC2FI vs. APCRBC2FIP vs. APCRBC2FI-PHR

Feature APCRBC2FI APCRBC2FIP APCRBC2FI-PHR
Battery Capacity 12V 7Ah 12V 9Ah 12V 9Ah (High Rate)
Battery Type Standard SLA Standard SLA High Rate SLA
Terminal Type F2/T2 (.250 inch) F2/T2 (.250 inch) F2/T2 (.250 inch)
Dimensions (LxWxH) 5.94 x 2.96 x 3.96 inches 5.94 x 2.96 x 3.96 inches 5.94 x 2.96 x 3.96 inches
Weight 4.5 lbs 5 lbs 5.5 lbs
Runtime Standard Extended Extended, High Load Support
Plug & Play Yes Yes Yes
Warranty 1 Year 1 Year 1 Year
Design Life 3–5 years at 77°F 3–5 years at 77°F 3–5 years at 77°F
Special Feature Standard APC replacement Higher capacity High rate for UPS/high load

Compatibility

Fits APC UPS models including: AP330, AP330XT+, AP360, AP360SX, AP600, Back-UPS 200/200B/250B/280/280B/300/400/400B/500M/500MC/700UC, Back-UPS CS500, Back-UPS Pro 280/280BPNP/280C/280PNP/280S/420/420C/420PNP/420S/500CLR/500U, Personal Powercell, Pro 350 USB, Smart-UPS 420/420NET/VS420, and more

Important Note

Batteries are heavy—verify your UPS model and terminal type before ordering. For compatibility questions, contact our customer support team. This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm (California Proposition 65)
