SPS Brand APCRBC2PHR (SG-RBC2-PHR) High Rate Replacement Battery Cartridge for APCRBC2 UPS

SPS Brand APCRBC2PHR (SG-RBC2-PHR) High Rate Replacement Battery Cartridge for APCRBC2 UPS

(No reviews yet) Write a Review

SKU:
SGRBC2PHR_1_AL000
UPC:
681827854511
Condition:
New
Availability:
Usually Ships in 24 hours
Weight:
5.30 LBS
Shipping:
Free Shipping
Volt:
12 V
Capacity:
9 Ah
LENGTH:
5.94 IN
WIDTH:
2.56 IN
HEIGHT:
3.96 IN
Weight:
5.3 LBS PER UNIT
TERMINAL:
T2
MSRP: $80.00
$40.00
(You save $40.00 )
Front view of the battery showing terminal connections and product labeling for APC RBC2PHR replacement battery. Compatible with CP40U48SC3 UPS models. 12V 7Ah battery with T2 terminals.

SPS Brand APCRBC2PHR (SG-RBC2-PHR) High Rate Replacement Battery Cartridge for APCRBC2 UPS

Key Features

  • High Rate Performance: Features a 12V 9Ah High Rate sealed lead acid battery, specifically engineered for UPS applications to support higher loads for shorter durations—ideal for critical backup and surge protection.
  • Plug & Play Installation: Arrives fully assembled, charged, and ready to install—no assembly required. Swap out your old cartridge in minutes.
  • Superior Quality & Freshness: Built with brand-new, voltage-matched batteries from ISO-certified factories. Shipped within one business day and backed by a 1-year full warranty.
  • Extended Compatibility: Direct replacement for APCRBC2 and compatible with a wide range of APC UPS models, including BackUPS, SmartUPS, and PowerCell series (see compatibility below).

Product Description

Upgrade your APC UPS with the SPS Brand APCRBC2-PHR (SG-RBC2-PHR) High Rate Replacement Battery Cartridge. This cartridge utilizes a 12V 9Ah High Rate battery designed for demanding UPS applications, providing additional runtime and superior performance during high-load events compared to standard and high-capacity alternatives. The RBC2-PHR is plug-and-play, arrives fully assembled and charged, and is built with premium, freshly manufactured batteries for maximum reliability and service life.

Technical Specifications

SpecificationDetails
Battery TypeSealed Lead Acid (SLA), High Rate, Rechargeable
Voltage12V
Capacity9Ah (36W @ 15min-rate to 1.67V/cell @ 25°C)
Maximum Discharge Current135A (5 seconds)
Dimensions5.94 x 2.96 x 3.96 inches
Weight5 lbs
Terminal TypeT2
Design Life3–5 years at 77°F (25°C)
Warranty1 year full warranty

Compatible Models

Fits APC models including: AP330, AP330XT+, AP360, AP360SX, AP600, BackUPS 200/200B/250B/280/280B/300/400/400B/500M/500MC/700UC, BackUPS CS500, BackUPS Pro 280/280BPNP/280C/280PNP/280S/420/420C/420PNP/420S/500CLR/500U, Personal Powercell, PowerCell Personal, Pro 350 USB, Professional PowerCell, SmartUPS 420/420NET/VS420, and more.

Comparison Table: APCRBC2 vs. APCRBC2P vs. APCRBC2PHR

FeatureAPCRBC2 (Standard)APCRBC2P (High Capacity)APCRBC2PHR (High Rate)
Battery TypeStandard SLAStandard SLAHigh Rate SLA
Voltage12V12V12V
Capacity7Ah9Ah9Ah
Max Discharge CurrentStandardStandard135A (5 sec)
RuntimeStandardExtendedExtended + Surge
Best ForTypical loadsLonger runtimeCritical loads / Surges
Plug & PlayYesYesYes
Warranty1 Year1 Year1 Year

Key Differences

  • APCRBC2: Standard 7Ah battery for general UPS use.
  • APCRBC2P: Higher 9Ah capacity for longer runtime at the same load.
  • APCRBC2PHR: 9Ah High Rate battery, delivering both extended runtime and superior high-load/surge performance, making it ideal for demanding or mission-critical backup scenarios.

Important Notes

  • Batteries are heavy; confirm compatibility before ordering.
  • California Proposition 65 Warning: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov.
  • APC® is a registered trademark of Schneider Electric IT Corporation. This product is not affiliated with or endorsed by Schneider Electric.
